Quality used Horton electric EC450 fan clutch for Cummins 5.9L engines, backed by our standard warranty.

BASE TO FAN 2.4
BOLT CIRCLE 3.81
Fan Pilot 3.25
FAN PILOT DIAMETER 3.25
FLANG DIAMETER 0.25 IN
Heavy Duty FALSE
MOUNTING BOLT CIRCLE 1.97
MOUNTING FLANGE DIAMETER 0.25
MOUNTING FLANGE THICKNESS 0.25
MOUNTING PILOT DIAMETER 1
Number of Bolts 4
NUMBER OF FAN MTG BOLTS 0.36
NUMBER OF SLOTS/HOLES 4
Overall Length 3.36
Pilot Depth 0.69
SLOT WIDTH/THREAD 0.36
Volts 12V

OEM # 996015, 4323445, 0177702, 3927735, 3692970, EC450, Bluebird 1477702, Bluebird 4323445, Tico 60423, 042003013, 042-003-013, 1477702, 4323445, 60423, 986000, 986062, 986063, 3912-996015, 3912996015, 4323445, 986000, 986062, 986063, 996015, HOR996015, ZBH9960151477702, 3912-996015, 3912996015, 4323445, 986000, 986062, 986063, HOR996015, ZBH996015

Please Note: The part sent may not exactly match the one pictured. Appearance may vary. For specific part requests, please call 888-315-2575. Additional core charge may apply.

32C-996015-STK
